NSmithy

From model to runtime

Describe operations, shapes, and traits once. dotnet build emits the server stub, the client, and the docs.

smithy build 0 errors

weather.smithy source

$version: "2"
namespace example.weather

use aws.protocols#restJson1

@restJson1
service Weather {
    version: "2024-01-01"
    operations: [GetForecast]
}

@readonly
@http(method: "GET", uri: "/forecast/{city}")
operation GetForecast {
    input := {
        @required
        @httpLabel
        city: String
    }
    output := {
        @required
        tempC: Float
        summary: String
    }
}

→

using Example.Weather; // generated

public class WeatherHandler : IWeatherHandler
{
    public Task<GetForecastOutput> GetForecastAsync(
        GetForecastInput input,
        CancellationToken ct = default)
    {
        return Task.FromResult(new GetForecastOutput(
            tempC: 18.4f,
            summary: $"Clear skies over {input.City}"));
    }
}

// register the handler, map the routes + docs
builder.Services.AddWeatherServiceHandler<WeatherHandler>();
app.MapWeatherService();  // REST routes -> /forecast/{city}
app.MapSmithyOpenApi();   // Scalar UI   -> /openapi
app.MapSmithyDocs();      // Sphinx docs -> /docs

using Example.Weather; // generated

IWeatherClient client = new WeatherClient(endpoint);

var forecast = await client.GetForecastAsync(
    new GetForecastInput(City: "Zurich"));

Console.WriteLine(forecast.Summary);
// Clear skies over Zurich

Fill in the typed handler, then register and map it — routing, serialization, and docs are wired for you.

The protocol is a trait on the model

Handler and client code stay the same. Changing the protocol trait on the service changes the wire format — REST, JSON-RPC, binary CBOR, or gRPC over HTTP/2.

GetForecast handler & client — unchanged

REQUEST

GET /forecast/Zurich HTTP/1.1
accept: application/json

RESPONSE

HTTP/1.1 200 OK
content-type: application/json

{
  "tempC": 18.4,
  "summary": "Clear skies over Zurich"
}

REQUEST

POST / HTTP/1.1
content-type: application/x-amz-json-1.1
x-amz-target: Weather.GetForecast

{
  "city": "Zurich"
}

RESPONSE

HTTP/1.1 200 OK
content-type: application/x-amz-json-1.1

{
  "tempC": 18.4,
  "summary": "Clear skies over Zurich"
}

REQUEST

POST /service/Weather/operation/GetForecast HTTP/1.1
smithy-protocol: rpc-v2-cbor
content-type: application/cbor

A1                        # map(1)
   64 63 69 74 79         #   "city"
   66 5A 75 72 69 63 68   #   "Zurich"

RESPONSE

HTTP/1.1 200 OK
smithy-protocol: rpc-v2-cbor
content-type: application/cbor

A2                        # map(2)
   65 74 65 6D 70 43      #   "tempC"
   FB 40 32 66 66 66 66   #   18.4
   67 73 75 6D 6D 61 72 79 #   "summary"
   77 43 6C 65 61 72 ...  #   "Clear skies …"

REQUEST

:method: POST
:path: /weather.Weather/GetForecast
:scheme: https
:authority: api.example.com
content-type: application/grpc+proto
te: trailers

00 00 00 00 08            # frame: 8 bytes
0A 06 5A 75 72 69 63 68   #   field 1 "Zurich"

RESPONSE

:status: 200
content-type: application/grpc+proto

00 00 00 00 1E            # frame: 30 bytes
0D 66 66 93 41            #   tempC = 18.4
12 17 43 6C 65 61 72 ...  #   summary "Clear …"
grpc-status: 0

Plain REST with JSON bodies and full HTTP semantics — the default for browser-facing APIs.

Part of the Smithy ecosystem

Smithy is the IDL behind AWS's public APIs. The same model works with the official Smithy code generators for other languages.

C# Java TypeScript Python Rust Swift Kotlin Go Scala Ruby Dafny

Generated API documentation

app.MapSmithyOpenApi() mounts an interactive Scalar explorer; app.MapSmithyDocs() serves the Sphinx reference — both generated straight from the model at build time.

Scalar OpenAPI explorer showing the GetForecast endpoint — Scalar explorer · `/openapi`

Sphinx reference documentation showing the GetForecast operation — Sphinx reference · `/docs`
